طراحی
پمپ مستغرق با تیغه برش (کاتر) برای نصب ثابت و متحرک در چاله های مرطوب با عملکرد مداوم.
کاربرد
برای استفاده در مناطق تجاری و مسکونی جهت فاضلاب حاوی مدفوع انسانی ، آب آلوده (با مقادیر کم شن و ماسه)
پمپاژ فاضلاب مطابق با استاندارد EN12050 ، پمپ ها الزامات استاندارد DIN EN 12050-1 را برآورده میکنند.
| Equipment / function |
|---|
| Radial cutting unit with double shear effect |
| ATEX approval |
| Thermal engine monitoring with bimetal sensor |
| Moisture monitoring in the engine |
| Connection cable with free cable ends |
| Single-phase AC motor with separate capacitor switch box |
Rated Engine Power P₂
1.1 kw-10.5kw
Pressure Connection
DN32 – DN50
Design
Submersible sewage pump for continuous
, duty for stationary and portable wet installation
.as well as for stationary dry installation
Application
: For the promotion in commercial areas of
wastewater with feces
dirty water (with small amounts of sand)
Wastewater pumping according to 12050
The pumps meet the requirements of DIN EN 12050-1
| Technical Data | Material |
|---|---|
| Mains connection: 1~230 V, 50 Hz or 3~400 V, 50 Hz | Pump housing: EN-GJL-250 (ASTM A48 Class 35/40B) |
| Operating mode immersed: Rexa PRO-S03: S1 Rexa PRO-S04: S1 |
Impeller: EN-GJL-250 (ASTM A48 Class 35/40B) |
| Operating mode changed: Rexa PRO-S03 up to 4 kW: S2-30 min; S3 25% Rexa PRO-S03 from 5 kW: S2-30 min; S3 10% Rexa PRO-S04: It is possible to replace the motor. The motor temperature defines the maximum operating time. The motor is equipped with a temperature control system at the factory for this purpose. |
Cutting unit: 1.4528/59 HRC (AISI 440B+Co) |
| Protection class: IP68 | Motor housing: EN-GJL-250 (ASTM A48 Class 35/40B) |
| Insulation class: F | Wave: Up to 2.5 kW: 1.4401 (AISI 316) From 3.9 kW: 1.4021 (AISI 420) |
| Media temperature: 3 … 40 °C (37 … 104 °F) | Sealing, engine side: C/MgSiO |
| Media temperature, max.: 60 °C (140 °F) for 3 min | Sealing, media side: SiC/SiC |
| Sealing, static: NBR (nitrile) |
